Axon Motor
1 / 5
| Gearbox with motor Data: | |||||||||
| GM1812-N20-11135-3.0V | |||||||||
| Reduction | 42 | 80 | 105 | 121 | 158 | 230 | 302 | 346 | 453 |
| Length(mm) | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
| No-load speed(rpm) | 267 | 140 | 107 | 93 | 71 | 49 | 37 | 32 | 25 |
| Rated speed(rpm) | 229 | 120 | 91 | 79 | 61 | 42 | 32 | 28 | 21 |
| Rated torque(kg.cm) | 0.05 | 0.10 | 0.13 | 0.15 | 0.19 | 0.23 | 0.30 | 0.35 | 0.45 |
| Stalling Torque (kg.cm) | 0.35 | 0.67 | 0.88 | 1.02 | 1.33 | 1.61 | 2.11 | 2.42 | 3.17 |
| GM1812-N20-05600-12.0V | |||||||||
| Reduction | 105 | 121 | 158 | 230 | 302 | 346 | 453 | 692 | 906 |
| Length(mm) | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
| No-load speed(rpm) | 219 | 190 | 146 | 100 | 76 | 66 | 51 | 33 | 25 |
| Rated speed(rpm) | 198 | 172 | 132 | 90 | 69 | 60 | 46 | 30 | 23 |
| Rated torque(kg.cm) | 0.13 | 0.15 | 0.19 | 0.23 | 0.30 | 0.35 | 0.45 | 0.69 | 0.91 |
| Stalling Torque (kg.cm) | 1.32 | 1.52 | 1.98 | 2.40 | 3.16 | 3.62 | 4.74 | 7.23 | 9.47 |
Our company was established in August 2009. It is a high-tech enterprise that integrates the research and development, production, and marketing of micro motor series products. The main products include: various precision DC motors, stepper motors, reduction motors, planetary reduction motors, and brushless motors.
Micro motors are widely used in medical equipment, medical detection and analysis, financial security, 5G applications, automotive appliances, intelligent communication, iris technology, AI intelligence, smart grid, smart home, commercial intelligent locks, smart switches, smart medicine cabinets, fresh food cabinets, smart wear, outdoor equipment, intelligent robots, electric tools, beauty tools, etc.
Since its establishment, the team has adhered to the concept of "people-oriented, pioneering and innovative spirit". After eleven years of rapid development, it has built a group of young, pragmatic, professional, and efficient work teams. Utilizing advanced production facilities, efficient management, excellent quality control, and high-quality services, we meet our customers' needs to continuously improve product levels, reduce energy consumption, facilitate production, and improve overall efficiency.
| Medical equipment | sphygmomanometer, Massaging mattress, Air pump, Urine Analyzer. |
| Business Machines | Intelligent robot, Copiers and Scanners, 3D Printers, Tattoo pen. |
| Electric powered equipment | Electric toothbrush, Electric tool, Electric toy car, Electric curtain. |
| Smart Home | Intelligent window opener, vacuum cleaner, Smart coffee machine, hair drier, Fascia gun, fan, air cleaner, Hair removal device, door lock, Intelligent door lock. |
| Food and Beverage | Hand Blenders, Blenders, Mixers, Coffee Machines, Food Processors, Juicers, Fryers, Ice Makers, Soy Bean Milk Makers. |
| Robotics | Servicing robotics, Food delivery robot, Reception robot, Medical serving robot, AGV & AMR, Conveying robot, Inspection robot. |
